For exact and efficient pressure testing of pipelines, vessels, boilers, cylinders, and industrial components, a hydro test system with a triplex plunger pump is utilized. The system’s smooth, pulsation-free functioning and steady pressure generation are guaranteed by its high performance engineering. Even in severe circumstances, its extended lifespan is provided by its sturdy design and precisely constructed equipment. The system’s large pressure range makes it appropriate for hydrostatic testing in a variety of sectors, including manufacturing, power, and oil and gas. It guarantees safe and effective operation with its pressure gauges, safety controls, and optional automation features. This system improves efficiency while upholding strict testing requirements, making it perfect for quality assurance, leak detection, and compliance testing. RENJET is dedicated to fulfilling consumer demands and strives to provide goods that may empower the manufacturing industry, benefit customers, and lead to mutual progress.
| MODEL SELECTION CHART | ||||
|---|---|---|---|---|
| Sr. No. | Model | Flow Rate (LPM) | Pressure (Bar) | Motor (HP) |
| 1 | EC 8.5/120 S | 8.5 | 120 | 3 HP (Single Phase) |
| 2 | EC 8.5/120 | 8.5 | 120 | 3 HP |
| 3 | EC 14/150 | 14 | 150 | 5 HP |
| 4 | EC 13/200 | 13 | 200 | 7.5 HP |
| 5 | EC 15/180 | 15 | 180 | 7.5 HP |
| 6 | EC 15/250 | 15 | 250 | 10 HP |
| 7 | EC 21/180 | 21 | 180 | 10 HP |
| 8 | EC 21/200 | 21 | 200 | 12.5 HP |
| 9 | EC 30/200 | 30 | 200 | 15 HP |
| 10 | EC 17/350 | 17 | 350 | 15 HP |
| 11 | EC 40/150 | 40 | 150 | 15 HP |
| 12 | EC 50/150 | 50 | 150 | 20 HP |
| 13 | EC 70/150 | 70 | 150 | 30 HP |
| 14 | EC 21/500 | 21 | 500 | 30 HP |
| 15 | EC 30/500 | 30 | 500 | 40 HP |
| 16 | EC 15/1000 | 15 | 1000 | 40 HP |
| 17 | EC 18/1000 | 18 | 1000 | 50 HP |
| 18 | EC 35/750 | 35 | 750 | 75 HP |
| 19 | EC 43/1000 | 43 | 1000 | 120 HP |
| 20 | EC 100/150 | 100 | 150 | 40 HP |
| 21 | EC 130/160 | 130 | 160 | 60 HP |
